FLUKE 124B FLUKE

Details

FLUKE 124B
FLUKE 124B
FLUKE 124B
FLUKE 124B
FLUKE 124B
FLUKE 124B
FLUKE 124B
FLUKE 124B
FLUKE 124B
  • FLUKE 124B
  • FLUKE 124B
  • FLUKE 124B
  • FLUKE 124B
  • FLUKE 124B
  • FLUKE 124B
  • FLUKE 124B
  • FLUKE 124B
  • FLUKE 124B

Manufacturer product page FLUKE

Scopemeter; 40MHz; colour,LCD TFT 5,7"; Ch: 2; 40Msps; 10n÷60s/div

Manufacturer code: FLUKE 124B

OMI code: 131132

Ask for special price (large quantity)
Shipping costs

Adding to order

In stock:

1 pcs

Qty.
[pcs] 		Price
[EUR/pcs]
1+ 3114.62

Price details
FLUKE 124B

Qty.
[pcs] 		Price
[EUR/pcs]
1+ 3114.62

Quantity pcs (multiplicity: 1)

Total: EUR

Specification

Show similar products –
Show similar products –
Manufacturer
FLUKE
IP rating
IP51
Manufacturer series
FLUKE 120B
Conform to the norm
EN 61010, CAT IV 600V, CAT II 750V
Related items
POM-72941, POM-72942
Dimensions
259x132x55mm
Number of channels
2
Kind of display used
colour, LCD TFT 5,7"
Power supply
rechargeable battery Li-Ion 10,8V x1, power supply 17,8V DC
Additional functions
multimeter
Standard equipment
battery charger/power supply, BNC to banana plug adapter, 2 x shielded test lead with ground lead, adapter WiFi USB, black test lead, blue and red grapple hook
Measuring instrument features
20 screens memory, Connect-and-View function that ensures stable, reliable and repeatable signal display without operator, IntellaSet™ technology automatically and intelligently adjusts numerical readout based on the measured signal, rugged design to withstand 3g Vibration, 30g shock, set actual value to reference, WiFi adapter connected to internal USB port to wirelessly transfer information to the PC, laptop or Fluke Connect® mobile app, zxternal optically isolated USB interface to transfer, archive and analyze scope or meter data
Display resolution
640x480
Measurement
DC voltage, resistance, AC voltage, active power, apparent power, harmonics, power factor, reactive power, capacitance, energy
Battery/ rechargeable battery
rechargeable battery Li-Ion 10,8V x1
Plug variant
EU
Optional equipment
240A AC/DC FLK-I200S current clamp probe, 400A AC/DC FLK-I410 current clamp probe, FLK-I310S - current clamp, FLK-I400S - current clamp
Continuity test
acoustic indication
Sampling
40Msps
Band
40MHz
Resistance measuring range
5kΩ, 50kΩ, 500kΩ, 5MΩ, 30MΩ, 500Ω
DC voltage measuring range
50V, 500V, 500mV, 5V, 750V
AC voltage measuring range
750V, 50V, 500V, 500mV, 5V
DC voltage measuring accuracy
±(0.5% + 5 digit)
Capacitance measuring range
5µF, 50µF, 500µF, 500nF, 50nF
Diode test
0.5mA @2.8V
Resistance measuring accuracy
±(0.6%+5 digit)
Type of oscilloscope
scopemeter
Time base
10n...60s/div
Gross weight 3026.90 g
Documentation in English #1 Documentation in English #2 Documentation in English #3 Documentation in English #4 Documentation in English #5 Documentation in English #6

Documentation is not automatically updated, but we do our best to provide the most up-to-date versions of documents.

See the rest of the products in this category: Portable Oscilloscopes, Scopemeters
