GDS-2102E GW INSTEK

Details

GDS-2102E
  • GDS-2102E

Manufacturer product page GW INSTEK

Oscilloscope: digital; DSO; Ch: 2; 100MHz; 1Gsps; 10Mpts; LCD TFT 8"

Manufacturer code: GDS-2102E

OMI code: 180753

Ask for special price (large quantity)
Shipping costs

Adding to order

In stock:

0 pcs

Qty.
[pcs] 		Price
[EUR/pcs]
1+ 1103.9

Price details
GDS-2102E

Qty.
[pcs] 		Price
[EUR/pcs]
1+ 1103.9

This product is currently out of stock. You can enable notification of new arrivals of this product. To do this, click on the "Notify" button and fill out the form.

Specification

Show similar products –
Show similar products –
Manufacturer
GW INSTEK
Manufacturer series
GDS-2000E
Dimensions
384x208x127.3mm
Interface
USB, LAN
Number of channels
2
Kind of display used
LCD TFT 8"
Standard equipment
mains cable, oscilloscope probe (1 per channel)
Measuring instrument features
automatic measurement of many parameters, AUTOSET function for setting display parameters (time base, gain), background noise filter, protocols analyse: CAN/LIN, protocols analyse: I2C, SPI, UART
Input impedance
1MΩ/16pF
Display resolution
800x480
Plug variant
EU
Sampling
1Gsps
Band
100MHz
Type of oscilloscope
digital
Input coupling
AC, DC, GND
Vertical resolution
8bit
Trigger modes
automatic, normal, single
Trigger coupling
AC, DC, highpass, lowpass
Max. input voltage
300V
Rise time
≤3.5ns
Input sensitivity
1mV/div...10V/div
Time base
1n...100s/div
Memory record length
10Mpts
Kind of oscilloscope
DSO
Gross weight 4156.70 g
Documentation in English #1 Documentation in English #2 Documentation in English #3 Documentation in English #4

Documentation is not automatically updated, but we do our best to provide the most up-to-date versions of documents.

See the rest of the products in this category: Digital Oscilloscopes
