RE72-131100M0 LUMEL

Details

RE72-131100M0
RE72-131100M0
RE72-131100M0
RE72-131100M0
RE72-131100M0
RE72-131100M0
RE72-131100M0
RE72-131100M0
RE72-131100M0
  • RE72-131100M0
  • RE72-131100M0
  • RE72-131100M0
  • RE72-131100M0
  • RE72-131100M0
  • RE72-131100M0
  • RE72-131100M0
  • RE72-131100M0
  • RE72-131100M0

Manufacturer product page LUMEL

Module: regulator; temperature; SPST-NO; OUT 2: analogue; on panel

Manufacturer code: RE72-131100M0

OMI code: 229076

Ask for special price (large quantity)
Shipping costs

Adding to order

In stock:

6 pcs

Qty.
[pcs] 		Price
[EUR/pcs]
1+ 174.81

Price details
RE72-131100M0

Qty.
[pcs] 		Price
[EUR/pcs]
1+ 174.81

Quantity pcs (multiplicity: 1)

Total: EUR

Specification

Show similar products –
Show similar products –
Manufacturer
LUMEL
Mounting
on panel
Operating temperature
0...50°C
IP rating
IP65 (from the front)
Manufacturer series
RE72
Supply voltage
85...253V AC
Body dimensions
48x48x93mm
Mounting hole diameter
45x45mm
Type of module
regulator
Kind of display used
LED
Kind of output 1
SPST-NO
The programming method
rubber keypad
Controlled parameter
temperature
Kind of temperature sensor
Pt100, thermocouple B, thermocouple E, thermocouple J, thermocouple K, thermocouple L, thermocouple N, thermocouple R, thermocouple S, thermocouple T, Pt1000
Regulation for output 1
ON-OFF, PID, AUTOTUNING, TIMER
Display parameters
4-digit
Output 1 electrical parameters
250V AC / 2A
Controlled parameter range
-999...9999
Kind of input 1
universal, 0/4...20mA, 0...5/10V
Input 1 properties
analogue voltage, current analog, RTD, thermocouple
Kind of output 2
analogue
Kind of output 3
SPST-NO
Output 2 electrical parameters
4...20mA
Output 3 electrical parameters
250V AC / 1A
Gross weight 202.99 g
Documentation in English #1 Documentation in English #2

Documentation is not automatically updated, but we do our best to provide the most up-to-date versions of documents.

See the rest of the products in this category: Temperature Regulators
