EC7BW18-72S05 CINCON

Details

EC7BW18-72S05
EC7BW18-72S05
EC7BW18-72S05
EC7BW18-72S05
EC7BW18-72S05
EC7BW18-72S05
EC7BW18-72S05
EC7BW18-72S05
EC7BW18-72S05
  • EC7BW18-72S05
  • EC7BW18-72S05
  • EC7BW18-72S05
  • EC7BW18-72S05
  • EC7BW18-72S05
  • EC7BW18-72S05
  • EC7BW18-72S05
  • EC7BW18-72S05
  • EC7BW18-72S05

Manufacturer product page CINCON

Converter: DC/DC; 20W; Uin: 8.5÷160V; Uout: 5VDC; Iout: 4000mA; THT

Manufacturer code: EC7BW18-72S05

OMI code: 2374

Ask for special price (large quantity)
Shipping costs

Adding to order

In stock:

0 pcs

Qty.
[pcs] 		Price
[EUR/pcs]
1+ 49.99
2+ 47.36

Price details
EC7BW18-72S05

Qty.
[pcs] 		Price
[EUR/pcs]
1+ 49.99
2+ 47.36

This product is currently out of stock. You can enable notification of new arrivals of this product. To do this, click on the "Notify" button and fill out the form.

Specification

Show similar products –
Show similar products –
Manufacturer
CINCON
Mounting
THT
Operating temperature
-40...85°C
Power
20W
Type of converter
DC/DC
Manufacturer series
EC7BW18
Output voltage
5V DC
Conform to the norm
EN 50155
Application
railway industry
Body dimensions
50.8x25.4x10.2mm
Output current
4A
Trade name
EC
Number of outputs
1
Insulation voltage
3kV DC
Input voltage
8.5...160V
Switching frequency
200kHz
Efficiency
85%
Protection
short circuit protection SCP, anti-overload OPP, over current OCP, voltage drop BOP
Gross weight 29.71 g
Documentation in English #1 Documentation in English #2

Documentation is not automatically updated, but we do our best to provide the most up-to-date versions of documents.

See the rest of the products in this category: DC/DC Converters
