C4AQSBW5220A3NJ KEMET

Details

C4AQSBW5220A3NJ
  • C4AQSBW5220A3NJ

Manufacturer product page KEMET

Capacitor: polypropylene; DC-Link; 22uF; ESR: 4.6Ω; THT; ±5%; 14V/μs

Manufacturer code: C4AQSBW5220A3NJ

OMI code: 247208

Ask for special price (large quantity)
Shipping costs

Adding to order

In stock:

0 pcs

Qty.
[pcs] 		Price
[EUR/pcs]
1+ 11.25
3+ 7.54
5+ 7.14
115+ 6.93

Price details
C4AQSBW5220A3NJ

Qty.
[pcs] 		Price
[EUR/pcs]
1+ 11.25
3+ 7.54
5+ 7.14
115+ 6.93

This product is currently out of stock. You can enable notification of new arrivals of this product. To do this, click on the "Notify" button and fill out the form.

Specification

Show similar products –
Show similar products –
Manufacturer
KEMET
Mounting
THT
Operating temperature
-40...105°C
Max. operating current
17A
Body dimensions
57.5x50x35mm
Manufacturer series
C4AQ
Conform to the norm
AEC Q200
Tolerance
±5%
ESR value
4.6Ω
Kind of capacitor
DC-Link
Max. operating voltage
1.5kV DC
Type of capacitor
polypropylene
Max. forward impulse current
308A
Terminal pitch
52.5x20.3mm
Capacitance
22µF
Climate class
IEC 60068-1, 55/105/56
Capacitor application
filtering
Pulse resistance
14V/μs
Gross weight 109.93 g
Documentation in English #1 Documentation in English #2

Documentation is not automatically updated, but we do our best to provide the most up-to-date versions of documents.

See the rest of the products in this category: THT Film Capacitors
