14020325402000 HARTING

Details

14020325402000
  • 14020325402000

Manufacturer product page HARTING

PCB terminal block; angled 90°; 10.16mm; ways: 3; on PCBs; tinned

Manufacturer code: 14020325402000

OMI code: 251547

Ask for special price (large quantity)
Shipping costs

Adding to order

In stock:

50 pcs

Qty.
[pcs] 		Price
[EUR/pcs]
50+ 11.2

Price details
14020325402000

Qty.
[pcs] 		Price
[EUR/pcs]
50+ 11.2

Quantity pcs (multiplicity: 1)

Total: EUR

Specification

Show similar products –
Show similar products –
Manufacturer
HARTING
Operating temperature
-40...110°C
Length
30.48mm
Current rating
60A
Flammability rating
UL94V-0
Connector series
har-flexicon®
Conform to the norm
UL
Connector pinout layout
1x3
Colour
black
Contact plating
tinned
Body material
polyamide
Contact material
brass
Height
29.3mm
Connector
terminal
Wire cross-section
0.5...16mm<sup>2</sup>
Contacts pitch
10.16mm
Terminal pitch
10.16x10.16mm
Electrical mounting
THT, screw terminal
Mechanical mounting
on PCBs
Wire size
20AWG...6AWG
Type of connector
PCB terminal block
Spatial orientation
angled 90°
Rated voltage
600V
Depth
18.3mm
Engineering PN
har-flexicon 10,16 TTSH-3 TB50 BK
Number of ways
3
Connectors features
assembling possibility
Gross weight 26.44 g
Documentation in English #1

Documentation is not automatically updated, but we do our best to provide the most up-to-date versions of documents.

See the rest of the products in this category: PCB terminal blocks
