AR654/S1/P/P/P/P/IP65 APAR

Details

AR654/S1/P/P/P/P/IP65
AR654/S1/P/P/P/P/IP65
AR654/S1/P/P/P/P/IP65
AR654/S1/P/P/P/P/IP65
AR654/S1/P/P/P/P/IP65
AR654/S1/P/P/P/P/IP65
AR654/S1/P/P/P/P/IP65
AR654/S1/P/P/P/P/IP65
AR654/S1/P/P/P/P/IP65
  • AR654/S1/P/P/P/P/IP65
  • AR654/S1/P/P/P/P/IP65
  • AR654/S1/P/P/P/P/IP65
  • AR654/S1/P/P/P/P/IP65
  • AR654/S1/P/P/P/P/IP65
  • AR654/S1/P/P/P/P/IP65
  • AR654/S1/P/P/P/P/IP65
  • AR654/S1/P/P/P/P/IP65
  • AR654/S1/P/P/P/P/IP65

Manufacturer product page APAR

Four channel regulator; 230VAC; on panel,panel; 0÷50°C; AR654

Manufacturer code: AR654/S1/P/P/P/P/IP65

OMI code: 252360

Ask for special price (large quantity)
Shipping costs

Adding to order

In stock:

1 pcs

Qty.
[pcs] 		Price
[EUR/pcs]
1+ 868.9
5+ 842.16

Price details
AR654/S1/P/P/P/P/IP65

Qty.
[pcs] 		Price
[EUR/pcs]
1+ 868.9
5+ 842.16

Quantity pcs (multiplicity: 1)

Total: EUR

Specification

Show similar products –
Show similar products –
Manufacturer
APAR
Mounting
on panel, panel
Operating temperature
0...50°C
IP rating
IP65 (from the front)
Manufacturer series
AR654
Supply voltage
230V AC
Body dimensions
96x96x79mm
Mounting hole diameter
92x89mm
Type of module
four channel regulator
Kind of display used
LCD TFT 3,5"
Kind of output 1
SPST-NO
The programming method
foil keypad, USB, RS485, computer disk, memory stick, Modbus
Additional functions
locked by password, transducers power supply 24V DC, display brightness adjustment, error messages on the LED display
Controlled parameter
pressure, temperature, speed, humidity, fluid flow
Kind of temperature sensor
Pt100, thermocouple B, thermocouple E, thermocouple J, thermocouple K, thermocouple N, thermocouple R, thermocouple S, thermocouple T, Pt1000, Ni100, Pt500
Regulation for output 1
PID, ON-OFF with hysteresis, AUTOTUNING, PROGRAM
Display resolution
320x240
Output 1 electrical parameters
250V AC / 5A
Controlled parameter range
-9999...99999
Kind of input 1
0...10V, 0...20mA, 4...20mA, universal, 0...60mV, 0...850Ω
Touchpad
yes
Input 1 properties
RTD, thermocouple, 4 channel
Kind of output 2
SPST-NO
Kind of output 3
SPST-NO
Output 2 electrical parameters
250V AC / 5A
Output 3 electrical parameters
250V AC / 5A
Kind of output 4
SPST-NO
Output 4 electrical parameters
250V AC / 5A
Gross weight 100.00 g
Documentation in English #1 Documentation in English #2

Documentation is not automatically updated, but we do our best to provide the most up-to-date versions of documents.

See the rest of the products in this category: Recorders
