HDS2202 OWON

Details

HDS2202
  • HDS2202

Manufacturer product page OWON

Handheld oscilloscope; 200MHz; LCD 3,5"; Ch: 2; 1Gsps; 8kpts

Manufacturer code: HDS2202

OMI code: 300459

Ask for special price (large quantity)
Shipping costs

Adding to order

In stock:

2 pcs

Qty.
[pcs] 		Price
[EUR/pcs]
1+ 288.64
3+ 273.51

Price details
HDS2202

Qty.
[pcs] 		Price
[EUR/pcs]
1+ 288.64
3+ 273.51

Quantity pcs (multiplicity: 1)

Total: EUR

Specification

Show similar products –
Show similar products –
Manufacturer
OWON
Manufacturer series
HDS200
Dimensions
198x96x38mm
Number of channels
2
Kind of display used
LCD 3,5"
Power supply
rechargeable battery Li-Ion 18650 3,7V 2600mAh x2
Additional functions
multimeter
Standard equipment
USB cable, case, power supply, test leads ( 2pcs.), adjusting tool, oscilloscope probe, test lead (BNC - crocodile clips) x2
Input impedance
1MΩ/16pF
Measurement
AC current, DC current, DC voltage, resistance, AC voltage, capacitance, continuity
AC current measuring range
10A, 200mA
Sampling
1Gsps
Band
200MHz
Resistance measuring range
200Ω, 2kΩ, 20kΩ, 200kΩ, 2MΩ, 20MΩ, 100MΩ
DC current measuring range
10A, 200mA
DC voltage measuring range
1kV, 200mV, 2V, 20V, 200V
AC voltage measuring range
200mV, 2V, 20V, 200V, 750V
AC current measuring accuracy
±(1% + 10 digit)
DC voltage measuring accuracy
±(0.3% + 5 digit), ±(0.3% + 10 digit) @200mV
Capacitance measuring range
200µF, 2µF, 2mF, 20µF, 20nF, 200nF
DC current measuring accuracy
±(0.8% + 10 digit)
AC voltage measuring accuracy
±(0.8% + 10 digit), ±(1% + 10 digit) @750V
Resistance measuring accuracy
±(0.8%+3 digit)
Capacitance measuring accuracy
±(3%+ 10 digit)
Type of oscilloscope
handheld oscilloscope
Input coupling
AC, DC, GND
Vertical resolution
8bit
Trigger modes
automatic, normal, single
Rise time
≤1.75ns
Memory record length
8kpts
Gross weight 1058.80 g
Documentation in English #1

Documentation is not automatically updated, but we do our best to provide the most up-to-date versions of documents.

See the rest of the products in this category: Portable Oscilloscopes, Scopemeters
