UTD1102C UNI-T

Details

UTD1102C
  • UTD1102C

Manufacturer product page UNI-T

Handheld oscilloscope; 100MHz; LCD TFT 5,7"; Ch: 2; 500Msps

Manufacturer code: UTD1102C

OMI code: 307643

Ask for special price (large quantity)
Shipping costs

Adding to order

In stock:

0 pcs

Qty.
[pcs] 		Price
[EUR/pcs]
1+ 515.58
3+ 512.4

Price details
UTD1102C

Qty.
[pcs] 		Price
[EUR/pcs]
1+ 515.58
3+ 512.4

This product is currently out of stock. You can enable notification of new arrivals of this product. To do this, click on the "Notify" button and fill out the form.

Specification

Show similar products –
Show similar products –
Manufacturer
UNI-T
Dimensions
268x168x60mm
Interface
USB OTG, USB Host
Number of channels
2
Kind of display used
LCD TFT 5,7"
Power supply
rechargeable battery Li-Ion 7,4V 4400mAh x1
Standard equipment
mains cable, test probe x2, adapter DC, shunt x2
Measuring instrument features
automatic measurement of many parameters, multimeter function
Display parameters
(5999)
Display resolution
320x240
Measurement
AC current, DC current, DC voltage, resistance, AC voltage, capacitance
Battery/ rechargeable battery
rechargeable battery Li-Ion 7,4V 4400mAh x1
AC current measuring range
6mA, 60mA, 600mA, 6A
Sampling
500Msps
Band
100MHz
Resistance measuring range
6kΩ, 60kΩ, 6MΩ, 600Ω, 60MΩ, 600kΩ
DC current measuring range
6mA, 60mA, 600mA, 6A
DC voltage measuring range
1kV, 600V, 600mV, 6V, 60V
AC voltage measuring range
600V, 600mV, 6V, 60V, 700V
AC current measuring accuracy
±(2% + 5 digit), ±(2.5% + 5 digit)@6A
DC voltage measuring accuracy
±(1% + 5 digit)
Capacitance measuring range
6nF, 60nF, 600µF, 6mF, 600nF, 6µF, 60µF
DC current measuring accuracy
±(1.2% + 5 digit), ±(1.5% + 5 digit) @6A
AC voltage measuring accuracy
±(1.2% + 5 digit)
Resistance measuring accuracy
±(1.2%+5 digit), ±(1.5%+5 digit)@(600Ω), ±(1.5%+5 digit)@(6MΩ), ±(1.5%+5 digit)@(60MΩ)
Capacitance measuring accuracy
±(4%+ 5 digit), ±(5%+10 digit) @ 6nF...6mF
Trigger
rising-edge, falling-edge, impulse width, alternate
Type of oscilloscope
handheld oscilloscope
Rise time
≤3.5ns
Input sensitivity
5mV/div...50V/div
Time base
5n...50s/div
Memory record length
7.5kpts
Gross weight 3500.00 g
Documentation in English #1

Documentation is not automatically updated, but we do our best to provide the most up-to-date versions of documents.

See the rest of the products in this category: Portable Oscilloscopes, Scopemeters
