E5GC-RX1DCM-000 OMRON

Details

E5GC-RX1DCM-000
E5GC-RX1DCM-000
E5GC-RX1DCM-000
E5GC-RX1DCM-000
E5GC-RX1DCM-000
E5GC-RX1DCM-000
E5GC-RX1DCM-000
E5GC-RX1DCM-000
E5GC-RX1DCM-000
  • E5GC-RX1DCM-000
  • E5GC-RX1DCM-000
  • E5GC-RX1DCM-000
  • E5GC-RX1DCM-000
  • E5GC-RX1DCM-000
  • E5GC-RX1DCM-000
  • E5GC-RX1DCM-000
  • E5GC-RX1DCM-000
  • E5GC-RX1DCM-000

Manufacturer product page OMRON

Module: regulator; temperature; SPST-NO; OUT 2: SPST-NO; on panel

Manufacturer code: E5GC-RX1DCM-000

OMI code: 325742

Ask for special price (large quantity)
Shipping costs

Adding to order

In stock:

2 pcs

Qty.
[pcs] 		Price
[EUR/pcs]
1+ 309.69
25+ 307.14

Price details
E5GC-RX1DCM-000

Qty.
[pcs] 		Price
[EUR/pcs]
1+ 309.69
25+ 307.14

Quantity pcs (multiplicity: 1)

Total: EUR

Specification

Show similar products –
Show similar products –
Manufacturer
OMRON
Mounting
on panel
Operating temperature
-10...55°C
IP rating
IP66 (from the front)
Supply voltage
24V DC, 24V AC
Body dimensions
24x48x93mm
Type of module
regulator
Kind of display used
LCD
Kind of output 1
SPST-NO
The programming method
keypad
Additional functions
heating or cooling control
Controlled parameter
temperature
Kind of temperature sensor
JPt100, Pt100, thermocouple B, thermocouple C, thermocouple E, thermocouple J, thermocouple K, thermocouple L, thermocouple N, thermocouple PLII, thermocouple R, thermocouple S, thermocouple T, thermocouple U
Regulation for output 1
ON-OFF, 2PID
Output 1 electrical parameters
250V AC / 2A
Controlled parameter range
-1999...9999
Input 1 properties
analogue voltage, current analog, thermocouple
Display height 1
10.5mm
Kind of output 2
SPST-NO
Output 2 electrical parameters
250V AC / 2A
Gross weight 142.80 g
Documentation in English #1

Documentation is not automatically updated, but we do our best to provide the most up-to-date versions of documents.

See the rest of the products in this category: Temperature Regulators
