DPM72-MP TDE INSTRUMENTS

Details

DPM72-MP
  • DPM72-MP

Manufacturer product page TDE INSTRUMENTS

Meter: network parameters; on panel; digital,mounting; LCD

Manufacturer code: DPM72-MP

OMI code: 358322

Ask for special price (large quantity)
Shipping costs

Adding to order

In stock:

5 pcs

Qty.
[pcs] 		Price
[EUR/pcs]
1+ 147.13

Price details
DPM72-MP

Qty.
[pcs] 		Price
[EUR/pcs]
1+ 147.13

Quantity pcs (multiplicity: 1)

Total: EUR

Specification

Show similar products –
Show similar products –
Manufacturer
TDE INSTRUMENTS
Mounting
on panel
Operating temperature
0...50°C
IP rating
IP65 from the front
Supply voltage
10...24V DC, 10...24V AC
Mounting hole diameter
68x68mm
Interface
USB
Kind of display used
LCD
Power supply
USB
Backlight colour
RGB
Measuring instrument features
MIN/MAX function, programmable alarm thresholds
Type of meter
network parameters
Display resolution
192x160
Measurement
AC current, DC current, DC voltage, AC voltage, frequency
Kind of meter
digital, mounting
AC current measuring range
0...10A
Dimensions (W x H x D)
72x72mm
Kind of measurement
indirect with 5A current transformer
Frequency measuring range
10...500Hz
DC current measuring range
-10...10A
DC voltage measuring range
-500...500V
AC voltage measuring range
0...500V
DC voltage measuring accuracy
±1%
DC current measuring accuracy
±1%
AC voltage measuring accuracy
±1%
Frequency measuring accuracy
±0.1Hz
Supported formats
CSV
Gross weight 196.57 g
Documentation in English #1

Documentation is not automatically updated, but we do our best to provide the most up-to-date versions of documents.

See the rest of the products in this category: Power Network Meters and Analyzers
