ACD-54NAV BEHA-AMPROBE

Details

ACD-54NAV
ACD-54NAV
ACD-54NAV
ACD-54NAV
ACD-54NAV
ACD-54NAV
ACD-54NAV
ACD-54NAV
ACD-54NAV
  • ACD-54NAV
  • ACD-54NAV
  • ACD-54NAV
  • ACD-54NAV
  • ACD-54NAV
  • ACD-54NAV
  • ACD-54NAV
  • ACD-54NAV
  • ACD-54NAV

Manufacturer product page BEHA-AMPROBE

Meter: multifunction; digital,pincers type; Øcable: 45mm; LCD

Manufacturer code: ACD-54NAV

OMI code: 395187

Ask for special price (large quantity)
Shipping costs

Adding to order

In stock:

0 pcs

Qty.
[pcs] 		Price
[EUR/pcs]
1+ 504.35
2+ 480.99

Price details
ACD-54NAV

Qty.
[pcs] 		Price
[EUR/pcs]
1+ 504.35
2+ 480.99

This product is currently out of stock. You can enable notification of new arrivals of this product. To do this, click on the "Notify" button and fill out the form.

Specification

Show similar products –
Show similar products –
Manufacturer
BEHA-AMPROBE
Dimensions
260x87x51mm
Kind of display used
LCD
Illumination
yes
Standard equipment
test leads, case, temperature probe
Measuring instrument features
automatic power-off, contactless voltage detector, PEAK HOLD MIN/MAX function, low-pass filter for measuring drive parameters, tester of phase order
Temperature measurement accuracy
±(1% + 0,8°C)
Display parameters
5 digits
Type of meter
multifunction
Temperature measuring range
-50...1000°C
True effective value measurement
True RMS
Measurement
AC current, DC current, DC voltage, resistance, temperature, AC voltage, active power, frequency, capacitance
Battery/ rechargeable battery
battery 6LR61 9V x1
Kind of meter
digital, pincers type
AC current measuring range
100A, 1kA
Frequency measuring range
20...10kHz
Resistance measuring range
1kΩ, 10kΩ, 100kΩ
DC current measuring range
100A, 1kA
Max. diameter of measured cable
45mm
DC voltage measuring range
100V, 1kV
AC voltage measuring range
1kV, 100V
AC current measuring accuracy
±(1.5% + 5 digit)
DC voltage measuring accuracy
±(0.7% + 2 digit)
Capacitance measuring range
400µF, 4mF, 4µF
DC current measuring accuracy
±(1.5% + 5 digit)
AC voltage measuring accuracy
±(1% + 5 digit)
Resistance measuring accuracy
±(1%+3 digit)
Frequency measuring accuracy
±(0.5%+3 digit)
Capacitance measuring accuracy
±(1.9%+ 8 digit)
Active power measurement
0.01...1MW
Gross weight 1042.30 g
Documentation in English #1 Documentation in English #2 Documentation in English #3

Documentation is not automatically updated, but we do our best to provide the most up-to-date versions of documents.

See the rest of the products in this category: Meters and AC/DC Clamp Probes
