LAS1GQF-11ZET/L/G/12V/S ONPOW

Details

LAS1GQF-11ZET/L/G/12V/S
LAS1GQF-11ZET/L/G/12V/S
LAS1GQF-11ZET/L/G/12V/S
LAS1GQF-11ZET/L/G/12V/S
LAS1GQF-11ZET/L/G/12V/S
LAS1GQF-11ZET/L/G/12V/S
LAS1GQF-11ZET/L/G/12V/S
LAS1GQF-11ZET/L/G/12V/S
LAS1GQF-11ZET/L/G/12V/S
  • LAS1GQF-11ZET/L/G/12V/S
  • LAS1GQF-11ZET/L/G/12V/S
  • LAS1GQF-11ZET/L/G/12V/S
  • LAS1GQF-11ZET/L/G/12V/S
  • LAS1GQF-11ZET/L/G/12V/S
  • LAS1GQF-11ZET/L/G/12V/S
  • LAS1GQF-11ZET/L/G/12V/S
  • LAS1GQF-11ZET/L/G/12V/S
  • LAS1GQF-11ZET/L/G/12V/S

Manufacturer product page ONPOW

Switch: vandal resistant; Pos: 2; SPDT; 3A/220VAC; 5A/24VDC; IP65

Manufacturer code: LAS1GQF-11ZET/L/G/12V/S

OMI code: 420581

Ask for special price (large quantity)
Shipping costs

Adding to order

In stock:

3 pcs

Qty.
[pcs] 		Price
[EUR/pcs]
1+ 15.44
2+ 11.28
4+ 10.69

Price details
LAS1GQF-11ZET/L/G/12V/S

Qty.
[pcs] 		Price
[EUR/pcs]
1+ 15.44
2+ 11.28
4+ 10.69

Quantity pcs (multiplicity: 1)

Total: EUR

Specification

Show similar products –
Show similar products –
Manufacturer
ONPOW
Type of switch
vandal resistant
Operating temperature
-25...55°C
IP rating
IP65
Leads
screw terminals
Manufacturer series
LAS1GQ
Contacts configuration
SPDT
Body material
stainless steel
Switching method
ON-ON
Mechanical durability
1000000 cycles
Electrical life
50000 cycles
Contact material
silver alloy
Body colour
silver
Mounting hole diameter
Ø19mm
AC contacts rating @R
3A / 220V AC
Number of positions
2
DC contacts rating @R
5A / 24V DC
Actuator colour
silver
Illumination
LED, ring
Max. contact resistance:
50mΩ
Backlight colour
green
Min. insulation resistance
1GΩ
Button shape
flat
Stable positions number
2
Operating Force
4N
Illumination voltage
12V
Button marking
POWER
Ring shape
rounded
Test voltage
2kV
Gross weight 27.70 g
