BM525S BRYMEN

Details

BM525S
BM525S
BM525S
BM525S
BM525S
BM525S
BM525S
BM525S
BM525S
  • BM525S
  • BM525S
  • BM525S
  • BM525S
  • BM525S
  • BM525S
  • BM525S
  • BM525S
  • BM525S

Manufacturer product page BRYMEN

Digital multimeter; LCD; (9999); Bargraph: 41segm.60x/s; 5x/s

Manufacturer code: BM525S

OMI code: 471513

Ask for special price (large quantity)
Shipping costs

Adding to order

In stock:

1 pcs

Qty.
[pcs] 		Price
[EUR/pcs]
1+ 254.37

Price details
BM525S

Qty.
[pcs] 		Price
[EUR/pcs]
1+ 254.37

Quantity pcs (multiplicity: 1)

Total: EUR

Specification

Show similar products –
Show similar products –
Manufacturer
BRYMEN
Conform to the norm
EN 61010, CAT IV 1000V
Related items
5790D, 5793D, 5794D, 5795D, 5797D, BKP60, EX871515, EX881602, EX881603, EX881605, PKT-PTA, PKT-PTF-10, PKT-PTF-20, PKT-PTF-25, PKT-PTF-30, PKT-PTF-40, PKT-PTF-50, PKT-PTF-55, PKT-PTF-56, PKT-PTF-60, SE027, SE028, SE029, SE030, SE031, SE059, SE060, SE061, SE062, SE001, SE002, SE003, SE004, SE000, TESTO-06020393, TESTO-06020645, TESTO-06024592, TESTO-06024892, TESTO-06280020, TESTO-06281292, TESTO-06287533, TP200, TP400, TP870, TP873, TP873-5M, TP882, TP-111, TP-112, TP-02, TP-03, TP-04, TP-06, TP-08, TP-09, TPK-59, TPK-62, UTT10K, UTT12
Kind of display used
LCD
Illumination
yes
Power supply
battery 6LR61 9V x1
Standard equipment
test leads, holster, drop-like K-type probe with banana clips
Measuring instrument features
automatic power-off, auto and manual ranging, HOLD function, MIN/MAX/MEDIUM function, indicates incorrect connection of test leads, two channel temperature measurement, logging of MAX, MIN, Autocheck function - automatic selection LoZ DCV, LoZ ACV, i Ω, CREST: logging of extreme values MAX, MIN and MAX-MIN of voltage and current impulses > 0,8ms
Temperature measurement accuracy
±(0,3% + 2°C)
Display parameters
(9999)
Type of meter
digital multimeter
Temperature measuring range
-50...1000°C
Duty cycle factor
0...100%
True effective value measurement
True RMS AC+DC, True RMS AC
Measurement
AC current, DC current, DC voltage, resistance, temperature, AC voltage, frequency, capacitance, duty cycle, relative
Battery/ rechargeable battery
battery 6LR61 9V x1
AC current measuring range
10A, 6mA, 60mA, 600mA, 6A, 0.1...600µA
Dimensions (W x H x D)
103x208x64.5mm
Continuity test
acoustic indication, 20Ω...300Ω
Frequency measuring range
1kHz, 10kHz, 50kHz, 1mHz...15Hz
Weight with battery
635g
Bargraph
41 segm. 60x/s
Sampling
5x/s
Pollution degree
2
Resistance measuring range
6kΩ, 60kΩ, 6MΩ, 60MΩ, 600kΩ, 100mΩ...600Ω
DC current measuring range
10A, 0.1...600µA, 6mA, 60mA, 600mA, 6A
DC voltage measuring range
600mV, 0.01...60mV, 9.999V, 99.99V, 999.9V
AC voltage measuring range
600mV, 0.01...60mV, 9.999V, 99.99V, 999.9V
AC current measuring accuracy
±(0.6% + 3 digit)
DC voltage measuring accuracy
±(0.08% + 2 digit)
Capacitance measuring range
600µF, 6mF, 600nF, 6µF, 60µF, 10pF...60nF, 25mF
DC current measuring accuracy
±(0.2% + 4 digit)
Diode test
0.4mA @2V
AC voltage measuring accuracy
±(0.5% + 3 digit)
Resistance measuring accuracy
±(0.1%+3 digit)
Frequency measuring accuracy
±(0.04%+4 digit)
Capacitance measuring accuracy
±(0.8%+ 3 digit)
Duty cycle factor measurement accuracy
3d/kHz + 2 digits
Gross weight 859.20 g
Documentation in English #1 Documentation in English #2 Documentation in English #3 Documentation in English #4 Documentation in English #5 Documentation in English #6

Documentation is not automatically updated, but we do our best to provide the most up-to-date versions of documents.

See the rest of the products in this category: Portable digital multimeters
