BK4054B B&K PRECISION

Details

BK4054B
  • BK4054B

Manufacturer product page B&K PRECISION

Generator: arbitrary, function; 30MHz; LCD TFT 4,3"; 480x272

Manufacturer code: BK4054B

OMI code: 49133

Ask for special price (large quantity)
Shipping costs

Adding to order

In stock:

0 pcs

Qty.
[pcs] 		Price
[EUR/pcs]
1+ 965.56
3+ 944.08

Price details
BK4054B

Qty.
[pcs] 		Price
[EUR/pcs]
1+ 965.56
3+ 944.08

This product is currently out of stock. You can enable notification of new arrivals of this product. To do this, click on the "Notify" button and fill out the form.

Specification

Show similar products –
Show similar products –
Manufacturer
B&K PRECISION
Operating temperature
0...40°C
Supply voltage
100...240V AC
Dimensions
263x96x295mm
Interface
USB, LAN
Number of channels
2
Kind of display used
LCD TFT 4,3"
Additional functions
frequency meter
Standard equipment
USB cable, manufacturer's calibration certificate, power supply, User manual in electronic version
Measuring instrument features
Direct Digital Synthesized (DDS) technology
Display resolution
480x272
Protection
short circuit protection SCP
Type of generator
arbitrary, function
Software
LabVIEW
Maximum waveform frequency
30MHz
Waveform frequency range
1µHz...30MHz (rectangular waveform), 1µHz...30MHz (sinus waveform), 1µHz...6MHz (arbitrary waveform), 1µHz...12,5MHz (pulse waveform), 1µHz...500kHz (triangle waveform)
Output parameters
impedance: 50Ω, amplitude at 50Ω load 2mVpp-10Vpp, <10MHz, amplitude without load: 4mVpp-20Vpp, <10MHz
Sweep mode
period: 1m...500s, mode: linear or logarithmic; up or down
Kind of modulation
AM, FM, FSK, PM, PWM, ASK, PSK, DSB-AM
Waveforms
impulse, arbitrary, sinus, triangle, noise, square
Supply voltage 400Hz
100...120V AC
Arbitrary waveform
record length: 16k, vertical resolution: 14 bit, sampling: 150Msps
pulse width
32.6...1E+15ns
Gross weight 4140.90 g
Documentation in English #1 Documentation in English #2 Documentation in English #3

Documentation is not automatically updated, but we do our best to provide the most up-to-date versions of documents.

See the rest of the products in this category: Generators and Frequency Meters
