AR518/WU APAR

Details

AR518/WU
  • AR518/WU

Manufacturer product page APAR

Module: meter; pressure,speed,temperature,humidity; 0÷10V,2÷10V

Manufacturer code: AR518/WU

OMI code: 98297

Ask for special price (large quantity)
Shipping costs

Adding to order

In stock:

0 pcs

Qty.
[pcs] 		Price
[EUR/pcs]
1+ 168.92
5+ 163.72

Price details
AR518/WU

Qty.
[pcs] 		Price
[EUR/pcs]
1+ 168.92
5+ 163.72

This product is currently out of stock. You can enable notification of new arrivals of this product. To do this, click on the "Notify" button and fill out the form.

Specification

Show similar products –
Show similar products –
Manufacturer
APAR
Mounting
on panel
Operating temperature
0...50°C
IP rating
IP20 at terminal side, IP54 (from the front)
Manufacturer series
AR518
Supply voltage
20...350V DC, 15...265V AC
Body dimensions
144x72x72mm
Mounting hole diameter
138x67mm
Type of module
meter
Kind of display used
LED
Kind of output 1
0...10V, 2...10V
The programming method
keypad
Additional functions
temperature compensation of thermocouple cold ends, universal input (selected from keypad), signalling of detected errors with a messages on the display, signal digital filtering, sensors supply voltage 24V DC / 30mA
Controlled parameter
pressure, temperature, speed, humidity
Kind of temperature sensor
Pt100, thermocouple B, thermocouple J, thermocouple K, thermocouple R, thermocouple S, thermocouple T, Pt1000, Ni100, Pt500
Display parameters
4-digit
Controlled parameter range
-1999...9999
Kind of input 1
0...20mA, 4...20mA, universal, 0...60mV, 0...10V DC
Input 1 properties
analogue voltage, current analog, RTD, thermocouple
Display height 1
25mm
Gross weight 295.00 g

Documentation is not automatically updated, but we do our best to provide the most up-to-date versions of documents.

See the rest of the products in this category: Temperature Regulators

* All prices are net prices (excluding VAT) and do not include transportation costs, which will be included in the order amount. Transportation costs are available in the tab "Method and cost of delivery"

Last viewed items

AR518/WU

AR518/WU

Manufacturer: APAR

Module: meter; pressure,speed,temperature,humidity; 0÷10V,2÷10V

In stock:

0 pcs

Price details
AR518/WU

Qty.
[pcs] 		Price
[EUR/pcs]
1+ 168.92
5+ 163.72
AR904.B/RS485
